22-16 A.W.G.
0.5-1.5 mm² |
B1 |
1.8 |
3.3 |
15.0 |
16-14 A.W.G.
1.5-2.5 mm² |
B2 |
2.4 |
4.0 |
15.0 |
12-10 A.W.G.
4-6 mm² |
B5 |
3.6 |
5.5 |
15.0 |
8 A.W.G.
8 mm² |
B8 |
4.6 |
7.0 |
21.0 |
6 A.W.G.
14 mm² |
B14 |
5.9 |
8.9 |
26.0 |
4 A.W.G.
22 mm² |
B22 |
7.7 |
11.4 |
29.0 |
2 A.W.G.
38 mm² |
B38 |
9.4 |
13.3 |
32.0 |
1/0 A.W.G.
60 mm² |
B60 |
11.4 |
15.4 |
36.0 |
2/0 A.W.G.
70 mm² |
B70 |
13.3 |
17.5 |
37.0 |
3/0 A.W.G.
80 mm² |
B80 |
14.5 |
19.4 |
38.0 |
4/0 A.W.G.
100 mm² |
B100 |
16.4 |
22.0 |
38.0 |
250/300 MCM
A.W.G.
150 m㎡ |
B150 |
19.5 |
26.5 |
54.0 |
300/350 MCM
A.W.G.
180 m㎡ |
B180 |
21.0 |
28.5 |
57.0 |
400/500 MCM
A.W.G.
200 mm² |
B200 |
24.0 |
32.5 |
63.0 |
500/600 MCM
A.W.G.
325 mm² |
B325 |
28.0 |
37.0 |
72.0 |
